| Temperature (working/Storage) | -100C to + 450C /-200C to + 550C |
|---|---|
| Humidity (working/Storage) | RH 10% to RH 95% |
| Operating Current | 1.0A |
| Operating Volatge | 100V-240V |
| Operating Power | 55W |
| Resolution | 1366X768 |
|---|---|
| Brightness | 250nit Typical |
| Dynamic contrast ratio | 3000 :1 |
| Viewing Angle(L/R) | 178 Degrees |
| Refresh Rate | 60Hz |
| Response Time Typ. | 6.5 ms (G to G) |
| Colors | 16.7M |
| Centre Color Co-ordinates (X/Y) | X = 0.275 +/-0.01, Y= 0.29 +/-0.01 |
| Color Temperature (K) | 10200K |
| MEMC | NA |
| Mechanical Dimension (H*V)mm | 712.085 x 410.570 mm |
| Active area (H*V)mm | 697.685 x 392.256mm |
| Modes | Standard / Dynamic / Movie/ ECO/ Gentle/Vivid/ Sport/Game/Personal |
|---|---|
| Aspect Ratio | 16:9 |
| Light Leakage Value | <0.3 nits |
| Eye care/Protect | NA. |
| BEE Rating | 2 |
| HDR | HDR10 |
| Sound O/P PCBA (W) | 2x8W |
|---|---|
| Speaker Rating (W) | 8 ohm10Wx2 |
| Speaker Type | Box speaker |
| Sound Modes | Standard/Music/Cinema/ News/Personal |
| BT Option | Yes |
|---|---|
| Remote range (Straight/ 30 Angle) | Straight: >=8m 30 Angle: >=6m |
| Power Rating | 100-240Vac/50~60Hz |
|---|---|
| Input power | 55W |
| Std by (Power) | ≤0.5W |
| CPU | ARM Cortex-A55/1.3GHz/Quad-core |
| GPU | G31MP2/Multi-Core |
| DDR | 1.5GByte DDR |
| eMMC flash | eMMC:8 GByte |
| MEMC | NA |
| RAM (type/Capacity) | 1.5G |
| ROM (type/Capacity) | 8G |
| Wifi module (model) | WIFI + BT(2.4G+5G)Model:RTL8822CU |
| AV (no/location) | YES (Mini) |
| RF (no/location) | YES |
| Ethernet (no/location) | RJ45 |
| Other 1 | headphone×1 |
| Dolby (Plus/Vision/Atmos) | Dolby Audio |
|---|---|
| HDMI | HDMI 1.4x2 |
| USB | USB 2.0x2 |
| Bluetooth | BT V5.0 |
| HDCP | Yes |
| Netflix | Yes |
| Chromecast | Yes, CTS; Google chromecast built-in |
| ARC | Yes, eARC |
| HDR (10,10+,Dolby Vision) | HDR10 |
| QLED | NA. |
| Amazon prime video | Yes |
| Android /SW Version | Android R (11.0) |
|---|---|
| Wi-fi direct | Yes,function ready |
| VOD | Yes, Netflix/YouTube/APV and India local VODs |
| Casting Option | Yes |
| Screen Saver | Yes |
| Power saver mode | Yes |
| Video calling option | Yes, support Google Meet |
| Web-cam support | Yes, only support some USB camera |
| Voice assistant | Yes, Google assistant |
| Web-Browser | Yes, download from Google play store |
| Input support (keyboard, Mouse) | Yes, Support some USB keyboard and USB mouse function |
| HDR (10,10+, Dolby Vision) | HDR10 |
| TV dimension (with stand) LxWxH | 716.6*198.3*478.1 |
|---|---|
| TV dimension (without stand) L x W x H | 716.6*82.2*424.2 |
| Wall mount Size | 200x200mm |
| Packing box dimension (Outer) | 790x136x500mm |
|---|
